全自動晾茬機是一種新型釀酒設備，具有速度快，效率高等特點。全自動晾茬機是由機架、風機、傳送帶、打料棍、下料裝置、以及出料管組成的，該機將攤晾、加漿、加曲、攪拌、卸料等工藝一次性加工完成的，與傳統工藝相比，大大的降低了勞動的強度，實現自動化生產。全自動晾茬機提高了冷卻效果、同時降低了功耗，還了以前設備自積堵塞現象，是理想的冷散設備。
The fully automatic stubble drying machine is a new type of brewing equipment with fast speed and high efficiency. The fully automatic stubble drying machine is composed of a frame, a fan, a conveyor belt, a feeding rod, a feeding device, and a discharge pipe. The machine completes the processes of spreading, adding pulp, adding yeast, stirring, and unloading in one go. Compared with traditional processes, it greatly reduces labor intensity and realizes automated production. The fully automatic stubble drying machine improves the cooling effect, reduces power consumption, and solves the problem of self accumulation and blockage in the previous equipment, making it an ideal cooling and dispersing device.
每臺全自動晾茬機都有接曲裝置組成，接曲裝置是全自動晾茬機比較重要的裝置之一。接曲裝置位于全自動晾茬機的底部，形成對下料口漏料的收集作用，從而節約物料，避免出現浪費的現象。下面介紹一下全自動晾茬機接曲裝置的特征：
Each fully automatic stubble drying machine is composed of a bending device, which is one of the important devices of the fully automatic stubble drying machine. The bending device is located at the bottom of the fully automatic stubble drying machine, forming a collection function for material leakage at the discharge port, thereby saving materials and avoiding waste. The following is an introduction to the characteristics of the fully automatic stubble drying machine's bending device:
1、在全自動晾茬機的加曲料斗下料口正下方、處于全自動晾茬機底部的傳動鏈條上方設置一接曲筐；
1. A curved basket is installed directly below the feeding port of the curved material hopper of the fully automatic stubble drying machine and above the transmission chain at the bottom of the fully automatic stubble drying machine;
2、接曲筐的兩端分別固定在全自動晾茬機支架的橫梁上；
2. The two ends of the connecting basket are respectively fixed on the crossbeam of the fully automatic stubble drying machine bracket;
3、接曲筐為一端抬起的折型護板；
3. The connecting basket is a folded protective plate that is lifted at one end;
4、且折型護板的抬起端設有調節螺栓用于調節接曲筐在橫梁上的折型高度；
4. And the lifting end of the folded protective plate is equipped with an adjusting bolt to adjust the folded height of the connecting basket on the crossbeam;
5、以接曲筐形成對加曲料斗下料口中漏料的收集結構。
5. A collection structure is formed by connecting the curved basket to collect the leaked material in the discharge port of the adding curved hopper.
6、本實用新型能有效地對漏料進行收集和二次利用，從而節約物料。
6. The utility model can effectively collect and reuse leaked materials, thereby saving materials.
